* Image is for reference only

L510-203-H1-U Teco-Westinghouse VFD | 3hp 230V Single Phase IN | 3 Phase OUT

SKU: L510-203-H1-U
$320.76
Sale $320.76
Description

Features

  • Chassis Style Enclosure (IP20)
  • Sensorless Vector or V/ Hz with Auto Torque Boost Feature
  • Extensive Diagnostic and Monitoring Capabilities
  • Din Rail Option
  • PID Control
  • 8 Preset speeds
  • Two Multi-Function Analog Input/ Qty 1 Analog Output
  • Built-in Modbus or BACnet Protocol Via RJ 45 Interface
  • UL, cUL, and CE Approved



Product Detail:
Drives Type L510 MICRO DRIVE
Amps 10.5
HP 3
Phase 1
Voltage 230
Enclosure CHASSIS
Height 5.67
Width 5.65
Depth 5.8
Approx. Weight 4.000 LB
Motor Compatibility & Sizing Guide
Input / Output Electrical Ratings
Parameter Specification
Input Voltage 230V Single Phase (1Φ)
Input Frequency 50 / 60 Hz
Output Voltage 0 – 230V Three Phase (3Φ)
Output Current (rated) 10.5 A
Motor HP Rating 3 HP (max)
Motor Voltage 230V, 3-Phase
Confirming Motor Compatibility
  • Check the nameplate: Motor must be rated 230V, 3-Phase. Dual-voltage motors (e.g., 230/460V) should be wired for 230V (low-voltage connection).
  • HP match: Motor nameplate HP should be 3 HP or less. Running a motor significantly under-rated for this drive is acceptable; oversizing is not.
  • FLA vs. drive output current: Motor Full Load Amps (FLA) must not exceed 10.5 A. Compare the nameplate FLA directly to the drive's rated output.
  • Motor type: Designed for standard AC induction motors. Verify compatibility with the manufacturer before use with permanent magnet or other specialty motor types.
Application Notes
  • Single-phase input draws higher current than three-phase input of equivalent kVA — ensure your supply circuit and breaker are sized appropriately for single-phase service.
  • Chassis (IP20) enclosure is intended for installation inside a control panel or enclosure. Not rated for direct outdoor or wash-down environments.
  • Output frequency range supports variable speed operation; consult motor manufacturer for minimum allowable operating speed on continuous-duty applications.
  • Do not use output contactors between the drive and motor while the drive is running. Parameter configuration is required before first run — refer to the L510 user manual.
