256TTFNA14833 Marathon Motor 20HP 1800RPM 256JM DP 230/460Volt 3Phase

SKU: 256TTFNA14833
$3,400.96
Sale $3,400.96
Description
  • This item replaces Leeson G151362.60

Nameplate Specifications

Phase: 3 Output HP: 20 Hp
Output KW: 14.9 kW Voltage: 230/460 V
Speed: 1765 rpm Service Factor: 1.15
Frame: 256JM Enclosure: Totally Enclosed Fan Cooled
Thermal Protection: No Protection Efficiency: 91 %
Ambient Temperature: 40 °C Frequency: 60 Hz
Current: 50.0/25.0 A Power Factor: 82
Duty: 15 Minute Insulation Class: F
Design Code: B KVA Code: F
Drive End Bearing Size: 6309 Opp Drive End Bearing Size: 6210
UL: Recognized CSA: Y
CE: Y IP Code: 55
