UNAVAILABLE CONTACT US FOR HELP
- Rugged die cast aluminum gear housing for maximum gear and bearing support
- Precision machined gearing, hardened for maximum load capability
- All gearing designed and rated to AGMA class 9 standards, and to withstand momentary shock overload of 200%
- Oversized output bearings for greater overhung load capacity and long life
- High carbon alloy output shaft provides maximum strength and rigidity
- All needle bearing journals are precision ground after heat treating to provide maximum fit and finish
- Heavy duty industrial oil seals keep lubricant in and dirt out
- Gears and bearings are splash lubricated with permanent, heavy duty gear oil
- Conduit box included as standard
Technical Specifications
| Rotation: |
Reversible |
Mounting: |
Special |
| Shaft Type: |
Parallel |
Overall Length: |
13.61 in |
| Frame Length: |
4.47 in |
Shaft Diameter: |
0.750 in |
| Shaft Extension: |
1.5 in |
Torque: |
238 LB-IN |
