* Image is for reference only

H1039L Century Motor 5HP 3450RPM R56HZ ODP 208-230/460 Volt 3 Phase

SKU: H1039L
$611.30
Sale $611.30
Description
  • Automatic reset thermal protector prevents overheating.
  • Patented MAXGuard® insulation system offers superior protection for use with a variable frequency drive.
  • Permanently lubricated, double-sealed bearings extend the lifetime of the motor.
  • Ambient temperature up to 70°C allows for consistent operation in a range of environments and applications.
  • Vertical/horizontal mounting for proper placement of the fan within airflow.
Specifications

Nameplate Specifications

Phase: 3 Output HP: 5.0 Hp
Output KW: 3.7 kW Voltage: 208-230-460 V
Speed: 3450 rpm Service Factor: 1.15
Frame: R56HZ Enclosure: Drip Proof
Thermal Protection: Thermally Protected Efficiency: 86.5 %
Ambient Temperature: 40 °C Frequency: 60 Hz
Current: 13.4-13.2/6.6 A Duty: Continuous
Insulation Class: B UL: Recognized
CSA: Y CE: N
Number of Speeds: 1

Technical Specifications

Electrical Type: Polyphase, Induction Type, Single Or Dual Voltage Starting Method: Across The Line
Poles: 2 Rotation: Reversible Counterclockwise
Mounting: Cushion Base Drive End Bearing: Ball
Opp Drive End Bearing: Ball Frame Material: Rolled Steel
Shaft Type: Keyed Overall Length: 14.56 in
Frame Length: 8.75 in Shaft Diameter: 0.875 in
Shaft Extension: 2.309 in

General Specifications

UPC: 786674022585 Weight: 50.00 LB
Packaged Length: 19.00 IN Packaged Width: 12.00 IN
Packaged Height: 10.00 IN HTC: 8501.52.4000
Country of Origin: Mexico
